Cement Mill Ball Mill Liners Mn18Cr2 Steel Casting Heat Treatment

Name: Cement Mill Ball Mill Liners Mn18Cr2 Steel Casting Heat Treatment
Brand: Chen's Liner
Price: 1 USD

Wholesale Cement Mill Ball Mill Liners Mn18Cr2 Steel Casting Heat Treatment from china suppliers

Place of Origin : Jiangsu,China (Mainland)

Brand Name : Chen's Liner

Model Number : DF049

MOQ : 2 Ton/Tons

Price : Discuss in email

Packaging Details : Packed by strong steel pallets; The load of each pallet is less than 2500kg; The castings are loaded

Delivery Time : It depends on quantity to be ordered.

Payment Terms : L/C,T/T

Supply Ability : 3000 Ton/Tons per Year

Certification : ISO 9001:2008

Material : Mn18Cr2 Steel

Application : Cement mills

Dimensions : As per drawing

Hardness : Less than HB300

Impact Value : More than AK10J

Product Name : Ball Mill Liners

Inspection : UT&MT

Surface quality : Good surface quality after shot blasting

Contact Now

Cement Mill Ball Mill Liners Mn18Cr2 Steel Casting Heat Treatment

Summarization

High Manganese Steel is a traditional wear-resistant steel,it is widely used for high impact working condition.The yield strength can reach 60,000--85,000 psi,tensile strength 120,000--130,000 psi,and elongation35%-50%.

Specification

Model Number	DF049
Material	High Mn Steel
Hardness	Less than HB300
Dimension	As per drawing
Process	Sand Casting
Impact Value	≥AK 100J
Inspection	Dimensional Inspection Chemical Composition Inspection Hardness Inspection UT Test
Application	Coal Mill,Cement Mill,Mining Industry etc.
MOQ	6Tons
Delivery Time	Depends on the quantity to be ordered.
Port	Shanghai
Package	Steel Pallets
Payment Terms	T/T,L/C

Technical Parameters

Item	High Cr White Iron	High Cr Alloy Steel	High Mn Steel	Ni-hard Cast Iron
C	2.4-3.2	1.1-2.2	0.9-1.3	2.4-3.6
Si	0.6-1.2	0.6-1.2	≤0.8	≤0.8
Mn	0.5-1.0	0.5-1.0	11.0-18.0	≤2.0
Cr	12.0-30.0	11.0-30.0	1.5-2.5	1.5-10
S	≤0.04	≤0.04	≤0.04	≤0.15
P	≤0.06	≤0.06	≤0.06	≤0.15
Mo	0.1-3.0	0.1-3.0	≤1.0	≤0.1
Cu	0.1-1.0	0.1-1.0	-	-
Ni	0-0.3	0-0.3	-	3.3-10
Re	-	-	-	-
Equivalent Specification	GB/T8263-1999 AS2027 Cr27 AS2027 CrMo 15/3 AS2027 CrMo 20/2/1 ASTM A532 Class Ⅲ Type A 25%Cr ASTM A532 Class Ⅱ Type B 15%Cr-Mo BS 4844 3E DIN1695 NFA32401		GB/T5680-1998 DL/T 681-1999 JIS G 5153-1999 ASTM A128 DIN GX120Mn12 AFNORZ120Mn12	GB/T8263-1999 AS2027/Ni-Cr1-550 AS2027/Ni-Cr2-500 AS2027/Ni-Cr4-500 AS2027/Ni-Cr4-600 AS2027/Ni-Cr4-630 ASTM A532 1-A,B,C,D ASTM A532 2-A,B,C,D,E ASTM A532 3-A
Material Type	Martensite Matrix		Austenitic Mn Steel	-
Hardness	HRC≥56		HB≤300	HRC≥56
Impact Value	AK≥4J		AK≥80J	-
